5-4
920509-645 Operator Manual Cycle and Control Value Programming
5.3 Cycles Menu Cycles menu is used for modifying cycles.
Cycle modifications include phases, phases parameters, cycle
name, etc.
See Table 5-1, Cycle Description Chart, for treatments and values
available.
NOTE: While scrolling through screens and menus, note the follow-
ing:
1) Refer to S
ECTION 3.2.5, OPERATOR TERMINAL TOUCH SCREEN, for
complete touch pads description.
2) Press X on touch screen to cancel modification and return to pre-
vious level screen.
3) Press OK on touch screen to save the modification and return to
previous level screen (OK button is only present on the last
menu, press right arrow to reach the last menu).
• Modifying a Cycle
To modify a preprogrammed or customized cycle, proceed as fol-
lows:
1. Access Supervisor mode as explained in S
ECTION 5.2.2,
A
CCESSING SUPERVISOR MODE. Display shows Supervisor Mode
screen:
2. Press Modify Cycles on touch screen. Display shows Cycles
screen:
3. Select and press appropriate cycle to modify. Display shows
Change Cycle screen.
• Change Name – to change cycle name use touch pad
appearing on screen. Press ENTER arrow to return to
Change Cycle screen.
• Change Icon – Select and press appropriate icon touch pad
to change cycle icon. Use RIGHT arrow touch pad to
advance screen until OK touch pad is available to confirm
modification and return to Change Cycle screen.
• Change Parameters – to change cycle parameters press
corresponding touch pad.
OK touch pad allows saving current treatment parameters.
LEFT and RIGHT arrow touch pads allow scrolling through
current treatment parameters.
Pressing X touch pad allows to cancel modification of cur-
rent treatment and returns to Change Cycle screen.
• Reset Cycles to Default – to reset default cycle values.
To Next Page
