3-4
920509-645 Operator Manual Component Identification
SILENCE BUZZER: Press SILENCE BUZZER on touch screen to
stop alarm buzzer.
ACK: Press ACK on touch screen to stop alarm buzzer and
acknowledge displayed FAULT messages.
DETAILS: Press DETAILS on touch screen to view current cycle
written data of parameters.
PRINT: Press PRINT on touch screen to print specific information
from the Cycle, Service and Supervisor modes.
CYCLES: Press CYCLES on touch screen to access Cycles menu.
GEARS: Press GEARS on touch screen to access Machine Setup
menu.
Progress Bar: Progress Bar is displayed on Chamber screen while
cycle(s) is (are) in progress to show cycle(s) progress.
3.2.6 Audible Signal An audible signal warns operator that an action must be taken.
