Tables 1-1 and 1-2 define certain symbols which may be on your Basil 4700 Cage and Bottle Washer components:
Table 1-1. Definition of Symbols on Unit
Symbol Definition
Protective Earth (Ground).
Fuse Identification.
Pump Rotation.
Attention, Consult Manual for Further Instructions.
Warning! Risk of Electrical Shock.
Table 1-2. Definition of Symbols on Nameplate
Symbol Definition
MODEL Model Number of Unit.
S/N Serial Number of Unit.
V_~ Volt, Number of Phase (3 or 1), Alternate Current.
WIRE Number of Wires in the Electrical Cable (Ground Not Included).
YEAR Year of Manufacture of Unit.
k Kilovolt.
A Amperage Rating of Unit.
Hz Hertz – Frequency of Unit.
