Steris Basil 4700 - 3.16 Exhaust Fan

3-13
Component Identification Operator Manual 920509-645
3.16 Exhaust Fan Exhaust Fan is mounted directly in washer exhaust line, on top of unit
(see Figure 3-10).
During unit operation, exhaust fan removes residual vapors from
wash chamber and directs vapors to building exhaust duct.
Figure 3-10. Exhaust Fan
