DESCRIPTION
51
764333-099
FIG. &
ITEM
NO.
PART
NUMBER
UNITS PER
ASSEMBLY
25a ELECTRICAL BOX AND CONTROL COLUMN ASSEMBLY .......... X
1 P 117015 881 CONNECTOR, Ground (see Detail A) ................................................. 4
2 P 117031 428 ANALOG OUTPUT MODULE, 8 PTS, COMPACTLOGIX ................... 1
3 P 117031 430 INNER-PLATE, Down, Control Box ..................................................... 1
4 P 117033 732 FUSE, 30A, 600V, LITTELFUSE ......................................................... 3
5 P 117042 320 POWER SUPPLY, 24V, 10A, SIEMENS ............................................. 1
6 P 117042 334 BREAKER, 1P, 5A, SCHURTER ......................................................... 1
7 P 117043 343 RELAY, Safety, 4NO-2NC, OMRON (see Detail B)............................. 3
8 P 117043 344 BASE, Safety Relay, OMRON (see Detail B)....................................... 3
9 P 117050 166 PROGRAMMABLE CONTROLER, COMPACTLOGIX A-B................. 1
10 P 117050 177 MODULE, 6 Inputs, RTD/Tank,1769-IR6 A-B...................................... 1
11 P 117050 226 END CAP LEFT TERMINATION MODULE ......................................... 1
12 P 117050 230 POWER SUPPLY, 1769-PA2 A-B ....................................................... 2
13 P 117050 231 END CAP RIGHT TERMINATION MODULE....................................... 2
14 P 117050 347 SCREEN, 2711P-T6C20A A-B ............................................................ 1
15 P 117051 412 PRINTER, Impact................................................................................. 1
16 P 117902 672 FUSE, CC Class, 10A, 600V................................................................ 3
17 P 117903 070 FUSE, 6 A, 600V, CC Class................................................................. 2
18 P 117907 539 DIODE, 1N4004 (see Detail B) ............................................................ 3
19 P 117908 128 ALARM, Audible, 95 dB, 120V ............................................................. 1
20 P 117909 743 FUSE, 8A, 250V, LITTELFUSE (see Detail B)..................................... 2
21 P 117909 751 HOLDER, Fuse, 3P, 30A, 600V ........................................................... 1
22 P 117909 787 TERMINAL, M16/12.N #125129.16 ENTRELEC (see Detail C) .......... 1
23 P 117909 788 TERMINAL, M16/12 #115129.14 ENTRELEC (see Detail C).............. 6
24 P 117909 792 HUB CAP, FEM12 #118618.01 ENTRELEC (see Detail C) ................ 3
25 P 117909 794 HUB CAP, FEM13U #199635.24 ENTRELEC (see Detail B) .............. 1
26 P 117909 796 HOLDER, Fuse, ML10/13.SF (see Detail B)........................................ 7
27 P 117909 799 BAR, Jumper, BJM12 #179618.16 ENTRELEC (see Detail C) ........... 3
28 P 117910 455 RELAY, DPDT #LY2-AC120 OMRON (see Detail A) .......................... 1
29 P 117910 456 BASE, Relay, 2 Poles (see Detail A).................................................... 1
30 P 117910 671 HOLDER, Fuse, 2 Pins, 30A, 600V ..................................................... 3
31 P 117911 125 CONTACTOR, 3RT1015-1AK61 SIEMENS (see Detail D) ................. 1
32 P 117911 128 RELAY, Overload, 1.4-2A, 208 V (see Detail D).................................. 1
33 P 117911 131 RELAY, Overload, 1.1-1.6A , 208 V (see Detail D).............................. 1
34 P 117911 655 CONTACTOR, 3RT1034-1AK60 SIEMENS, 208 V (see Detail D) ...... 1
35 P 117911 661 OVERLOAD, 11-16, 400/480 V (see Detail D)..................................... 1
36 P 117911 663 OVERLOAD, 22-32A, 208 V (see Detail D) ........................................ 1
37 P 117911 768 RELAY, Overload, .55-.80A400/480 V (see Detail D).......................... 1
38 P 117911 822 CONTACTOR, 3RT1025-1AK60 SIEMENS, 400/480 V (see Detail D) 1
39 P 117911 831 OVERLOAD, .7-1A400/480 V (see Detail D) ....................................... 1
Continued...
