Hint
New water pipe installations:
Leave the water to run for a few minutes to flush any debris from the pipe before
connecting the machine to the water supply.
Connecting the water inlet hose
Connect the 90°-angle end of the water inlet hose to the water inlet on the back of the machine:
1. Insert the filter gasket in the coupling nut with the flat side against the water inlet hose.
2. Tighten the coupling nut firmly.
Connect the straight end of the water inlet hose to the water supply tap for cold water:
1. If needed, connect the reduction piece with gasket to the water supply tap.
2. Tighten the coupling nut firmly.
5.6.2 Connecting to the waste water outlet
1. Connect the elbow pipe to the waste water outlet pipe.
2. Connect the waste water outlet hose to the elbow pipe. If needed, lubricate with grease or soap
to make it easier to insert the pipe in the hose. Use a hose clamp to fasten the hose to the pipe.
3. Lead the other end of the waste water hose to the waste water drain.If needed, shorten the
hose.
Note
Make sure that the hose slopes downward towards the waste water drain throughout
its entire length.
Make sure that there are no sharp bends in the waste water hose.
5.7 Recirculation unit
To ensure optimal cooling, mount a recirculation unit on the machine.
Note
Before you connect the recirculation unit to the machine, you must prepare it for use.
See the Instruction Manual for this unit.
ELECTRICAL HAZARD
The pump of the recirculation cooling unit must be earthed (grounded).
Make sure that the electrical power supply voltage corresponds to the voltage stated
on the type plate of the pump.
Incorrect voltage can damage the electrical circuit.
5.7.1 Connecting the recirculation cooling unit to the water inlet
To connect the recirculation cooling unit follow these steps:
22 LaboPol-30
5 Installation
