12.3.1 LaboForce-100 - the specimen mover head
Cleaning
LaboForce-100 is equipped with a function for cleaning the feet that apply the force on the
specimens and also for cleaning the lock that secures the specimen mover plate for single
specimens.
The force on the pressure feet is generated by friction pins held in place by the screws in the
spring housing.
Clean the pressure feet and pistons applying the force on the specimens and specimen holder.
Procedure
1. Press the release outlet valve to drain the water/oil filter. See the section
LaboForce-100 - Empty the water/oil filter ►88.
2. From the Main menu select Maintenance > Cleaning of specimen mover
head.
3. Press F1 to activate one of the functions shown.
Note
Never force any of the movements. If the components do not move as they
should, contact Struers Service.
– Lower feet The pistons can be cleaned or lubricated.
– Raise feet Moves the feet back into operating position.
– Holder up Moves the specimen mover head up for cleaning.
– Holder down Moves the specimen mover head back into operating
position.
12.4 Monthly
12.4.1 LaboForce-50 - pressure feet
The force on the pressure feet is generated by friction pins held in place by the screws in the
spring housing.
