DE-109
Anschlussdiagramm für 1488HD
POWER
24 V
OPTICAL
DVI
VGAC-Video
R/Pr
G/Y
B/Pb
H-sync
V-sync
RS232
HD/SD
SDI IN
HD/SD
SDI OUT
S-Video
POWER
Switch
4
2
3
1
5
SDC3
Videokamera 1488HD
Lichtquelle L9000
WiSe-HDTV-Bildschirm (26") für chirurgische Verfahren
