Stryker FL23SE - CPR Emergency Release

www.stryker.com 72-1048E MM FL23SE REV A 113
Return To Table of Contents
CPR Emergency Release
CPR Emergency Release (For Reference Only: OL230227G, Rev. 00)
Item Part No. Part Name Qty.
1 23-0736Z Micro Switch Support 1
2 1325P003 Micro Switch 1
3 17-0192 Nut for Micro Switch 1
4 20-0015Z Activation Handle Bracket 2
5 20-0242G Activation Handle 2
6 20-0017Z Activation Mechanism Socket 1
7 20-0018Z Mobile Lever 1
8 20-0019Z Fixed Lever 1
9 25-0362Z Mattress Support Lever 1
10 25-0456Z Sleeve 1
11 25-0514Z Cylinder Inner Sleeve 1
12 25-0515Z Cylinder Outer Sleeve 1
13 M0008 Threadlocker -
Medium Strength (Blue) .3000
14 M0019 Petro Canada OG2 Grease .0450
15 QDF17-0020 Shoulder Spacer Diameter
5/16” x 0.210” 7
18 J2
J2 BROCHES 8 & 9
CARTE CONTROLE
1
39
34
COM.
N.O.
