Stryker FL23SE - Brake Mechanism with Fifth Wheel

www.stryker.com 72-1048E MM FL23SE REV A 73
Return To Table of Contents
Brake Mechanism with Fifth Wheel (For Reference Only: OL230043G, Rev. 02)
Item Part No. Part Name Qty.
1 25-0291G Linking Rod - Foot S.A. 1
2 25-0292G Linking Rod - Head S.A. 1
3 25-0340 5/16 X 3/16 Spacer 4
4 25-0451 Lever Spacer 2
5 QDF7878 Rue Ring Cotter Diameter
3/8” z.p. 2
6 QPA23-0233 Locking Axle 2
7 QPA25-0411 Brake Lever 2
8 QPA25-0427 Locking Lever 2
9 VB35A1O28FT Long Neck Carriage Bolt
5/16 - 18 X 7-8” Grade 5, z.p. 4
10 VE79A1O UNC Grade C ESNA Nut 5/16 - 18 4
11 VW10A10 Flat Washer 5/16” SAE z.p. 4
12 VW10C162404 Nylon Washer 1/2” Int. x
3/4” Ext. x 1/8” ep. 2
Brake Mechanism with Fifth Wheel
