FOOT END CASING CONNECTOR REPLACEMENT (OPTIONAL)
Tools Required:
No. 2 Phillips Screwdriver •
3/8” Combination Wrench•
Procedure:
Note
Unless otherwise indicated, refer to Figure 4.2 A on pg. 32 for the following replacement procedure.
Completely raise the bed and apply the brakes. 1.
Unplug the bed power cord from the wall outlet. 2.
Remove the foot board. 3.
Using the No. 2 Phillips screwdriver, remove the 10 screws (A) holding the cover and the two I.V. pole holders to the 4.
foot casing.
Lift and remove the cover taking care to disconnect the electronic board, the control panel cable (B) and the foot 5.
casing connector cable (C). Lay the cover on a workbench.
Using the 3/8” combination wrench, remove the two locknuts, shoulder spacers and screws (E) holding the connector 6.
and the seal (F) to the cover. Remove the defective connector using the 3/8” combination wrench and No. 2 Phillips
screwdriver. Keep the seal for the replacement connector.
Reverse the above steps to install the new connector. 7.
Verify all the controls of the foot end control panel for proper operation before returning the bed to service.8.
