FULL-LENGTH SIDERAIL ASSEMBLY REPLACEMENT
Tools Required:
No. 2 Phillips Screwdriver•
Two 1/2” Combination Wrenches•
Procedure:
Note
Unless otherwise indicated, refer to Figure 4.1 B on pg. 26 for the following replacement procedure.
Completely raise the bed and raise the siderail needing repair. 1.
Unplug the bed power cord from the wall outlet.2.
Remove the head and foot boards. 3.
Using two 1/2” combination wrenches, remove the two locknuts and bolts (K, Figure 4.3 C, 4. pg. 43) holding the two
bumpers to their supports at the head end of the bed.
Using the no. 2 Phillips screwdriver, remove the seven screws (Q, Figure 4.3 C, 5. pg. 43) holding the cover to the head
end casing. Remove the cables connected to the power connector after having noted their location and remove the
cover.
Using the no. 2 Phillips screwdriver, remove the 10 screws (A, Figure 4.2 A, 6. pg. 32) holding the cover and the I.V.
pole holders to the foot casing. Lift and remove the cover while taking care to disconnect the control panel cable
(B, Figure 4.2 A, pg. 32) from the control board and, if applicable, the foot end casing connector cable (C, Figure
4.2 A, pg. 32) (optional).
Using the no. 2 Phillips screwdriver, remove the four screws (D) holding together the two parts of both siderail 7.
mechanism covers. Remove the covers.
Using the 1/2” combination wrench, remove the four nuts, washers and bolts (E) holding the siderail release handle 8.
to the seat section.
Using the 1/2” combination wrench, remove the two nuts, washers and bolts (F) holding each end of the full-length 9.
siderail to the head end and foot end casings.
Reverse the above steps to install the replacement siderail assembly. 10.
Verify the siderail for proper operation before returning the bed to service.11.
