Tools Required:
No. 2 Phillips Screwdriver •
9 mm Combination Wrench •
Procedure:
Note
This connector is present when the bed is equipped with a foot board control panel.
Unless otherwise indicated, refer to Figure 4.2 B on pg. 34 for the following replacement procedure.
Completely raise the bed and apply the brakes. 1.
Unplug the bed power cord from the wall outlet. 2.
Remove the foot board and lay it on a workbench. 3.
Using the No. 2 Phillips screwdriver, remove the seven screws (A) holding the support cover to the inner face of the 4.
foot board and remove the cover.
Disconnect the foot board connector cable (B). 5.
Using the 9 mm combination wrench and No. 2 Phillips screwdriver, remove the two locknuts, washers, sleeves and 6.
screws (D) holding the connector to its support. Remove the defective connector.
Reverse the above steps to install the replacement connector. 7.
Verify the foot board controls for proper operation before returning the bed to service.8.
FOOT BOARD CONNECTOR REPLACEMENT (OPTIONAL)
Service Information
