FIFTH WHEEL CASTER REPLACEMENT (OPTIONAL)
Tools Required:
Two 1/2” Combination Wrenches•
Procedure:
Note
Unless otherwise indicated, refer to Figure 4.4 A on pg. 58 for the following replacement procedure.
Completely raise the bed. 1.
Unplug the bed power cord from the wall outlet. 2.
Position the brake/steer pedal to neutral. 3.
Using two 1/2” combination wrenches, remove the nut and bolt (C) holding the caster to the swing arm. 4.
Reverse the above steps to install the replacement caster.5.
Service Information
