www.stryker.com 72-1048E MM FL23SE REV A 147
Return To Table of Contents
Siderail Module Communication Cable Connections
Positions on the Connector Signal Color
3 Raise Fowler Brown
6 Raise Bed Blue
9 Raise Gatch Orange
8 Communication Black
7 Lower Gatch White
4 Lower Bed Green
1 Lower Fowler Red
10 Normally Open Buzzer Yellow
11 Communication Buzzer Grey
12 Normally Closed Buzzer Purple
Retractable Half-Length Siderails with Fixed Control
