Retractable Painted Siderails with Removable Controls
Retractable Painted Siderails with Removable Controls (For Reference Only: OL230246G, Rev. 00)
Item Part No. Part Name Qty.
1 23-0188 Siderail Support and Insert 2
2 23-0650G Siderail Support 2
3 23-0769G Painted Head Right Siderail 1
4 23-0770G Painted Head Left Siderail 1
5 23-0785G Painted Foot Right Siderail 1
6 23-0786G Painted Foot Left Siderail 1
7 QPCE1207 Cap 1
8 QP18-0240-07 Anchoring - Left Glider 8
9 QP18-0243-07 Anchoring - Right Glider 8
10 QP23-0389 Removable Control Panel Support 4
11 QP18-0241-07 Rear Glider - Right 4
12 QP18-0242-07 Rear Glider - Left 4
13 VB15A1N44 Bolt 1/4-20 x 1 3/4” Grade 5 16
14 VB35A1N44 Carriage Bolt 1/4-20 x 1 3/4”
Grade 5 4
15 VE30A1N Nylon Locknut 1/4-20 20
16 VV37A1N24-S Machine Screw Truss Phillips
1/4-20 x 3/4” Scotch Grip 4
17 VV83A9G24 Tapping Screw Pan Phillips
Type B #10 x 3/4” z.p. 8
18 VW10A08 Flat Washer 1/4” x 1/16 4
19 M0019 Petro Canada OG2 Grease .0300
20 QP23-0735 PCB Support 8
21 QDF7908 Black Plug 1” #SQR-1-10-14 4
22 QDF299X Adhesive Neoprene 1/4 x 3/4 .3333
