48 72-1048E MM FL23SE REV A www.stryker.com
Return To Table of Contents
HI-LO ACTUATOR REPLACEMENT (CONTINUED)
CAUTION
The course of the replacement motor must be adjusted prior to hooking it to the bed lift lever. An improper adjustment
can damage the bed lift mechanism.
To adjust the replacement motor, proceed as follows:12.
Once the replacement motor cable is connected, plug the bed power cord and press the bed down control until A.
the motor stops. This will be the lower limit of the actuator course.
Link the motor to the bed lift lever. B.
The alignment jigs still in position, completely raise and lower the bed to ensure that the lower limit has been C.
preserved following the motor replacement.
Service Information
