EN-6
transformers and printers can be installed without the use of an additional
transformer� Please contact your Stryker Endoscopy sales representative to
determine if your cart includes this feature�
3� Connect the AC power�
• Connect the provided hospital power cord to the AC inlet on the rear console panel�
• Connect the other end to a hospital-grade power outlet�
• Use a hospital power cord, part number 0105033001 or part number 0105150027�
Warning
• Check the power cord assembly periodically for damaged insulation or
connectors�
• To avoid risk of electric shock, this equipment must only be connected to a
supply mains with protective earth�
4� (Optional) Connect the equipotential ground probe to an equipotential bus bar (if available)�
The ground probe is provided to ensure all devices installed on the cart are connected to the
same ground potential� Ensure all connections are made according to the requirements of
IEC 60601-1�
5� (Optional) Connect the SDC3 to the WiSe Receiver�
• Insert the LED token provided with the WiSe receiver into the token slot on the front of
the SDC3 console according to the sequence of steps described in the WiSe receiver user
guide�
• When the LED light is o, no link is active, and the token can be inserted to begin
synchronization�
• When the LED light displays green, the link is active, and it is okay to remove the token�
• When the LED light displays amber, the system is busy and the token should not be
inserted or removed�
Note: The SDC3 can only be linked to one WiSe Receiver.
