EN-17
Synchronized Video Recording of Dual Channels
When two video sources are connected to the SDC3, the system can record synchronized
video from both video sources� In Synchronized Capture mode, images and video are captured
simultaneously from both channels, but saved as separate les�
Note: Dual Channel mode must be selected in the General Application settings screen to
enable this function.
2
5 43
1
To record synchronized video from dual channels:
1� Select the SYNCHRONIZED CAPTURE tab�
2� Press the CAPTURE , RECORD , and STOP buttons under the preview pane to
perform the corresponding function�
3� Press the PRINT
button to print images� When printing from the Synchronized Capture
screen, by default, images from Channel 1 will be printed rst and images from Channel 2
will be printed second�
To stream Dual Channel video:
4� Select the Stream 1 checkbox to stream Channel 1 video, or the Stream 2 checkbox for
Channel 2�
5� Press the STREAM button to start/stop streaming�
