EN-22
Video Settings: Picture-in-Picture
Picture-in-Picture settings are accessible from the VIDEO SETTINGS tab�
5
1
4
32
1� Pressing the PIP tab displays to the Video Settings: Picture in Picture (PIP)” screen�
2� The Picture by Picture (PBP) checkbox can be selected to view video inputs adjacent to
each other in the main preview screen� The PIP Size, and Select PIP Location options will be
disabled if PBP is selected�
3� Pressing the button closes the settings screen and returns to the Capture screen�
4� Pressing one of the numbers selects in which quadrant of the main picture the PIP will
appear
5� Pressing the PIP SIZE button toggles between Small, Medium and Large�
