S Class 2 cutter Service manual
Introduction 1-2
Replacement guidelines contains the following:
An overview of the removal and the replacement of various parts of the unit in the form of
separate sections. It is advisable to carefully read the procedure described in each of the
sections prior to removing or replacing a particular part. In addition to straightforward step
by step procedures you will often find Notes and Cautions. Make sure you read these remarks
as they will often facilitate re-installation and avoid malfunctioning.
Calibration contains the following
An overview of all the possible calibrations of the unit. Each time the machine is serviced
check this section to see if any recalibration needs to be done.
Error messages contains the following:
This part contains an overview of the error messages that can appear on the touch screen and
how to react.
Menu structure contains the following:
This part contains an overview of the various tests and configurations that can be accessed
via the touch screen.
Maintenance contains the following:
An overview of the maintenance of various parts of the unit. It is advisable to carefully read
the procedure described in each of the sections prior to removing or replacing a particular
part. You will often find Notes and Cautions. Make sure you read these remarks as they will
often avoid malfunctioning.
Figures - part numbers:
Detailed figures of the various parts and assemblies of the machine.
Spare parts list
An overview of all the recommended spare parts. Normally only the parts figuring on this list
will be provided by Summa.
Consumables list:
An overview of all the consumables
