S Class 2 cutter Service manual
Replacements guidelines 2-3
2.3 Removing the left-hand cover
To remove the left-hand cover, proceed as follows:
1. Remove the five screws holding the left-hand cover in place. Three are located at the
front, two at the rear. Pay close attention to where each of the screws goes. They should
be returned to their original location when re-installed.
2. Gently tap the top of the cover, lift it and slide outwards.
3. Remove the cover.
To re-install, proceed in the reverse order of removal. Make sure to firmly tighten all screws.
2.4 Removing the right-hand cover
To remove the right-hand cover, proceed as follows:
1. Remove the power cord and the communication cable.
2. Remove the 5 screws holding the left-hand cover in place. Three are located at the front,
one at the rear and one just above the USB connection. Pay close attention to where each
of the screws goes. They should be returned to their original location when re-installed.
3. Gently tap the top of the cover, lift it and slide outwards.
Note:
The touch screen is built in in the cover. It is connected with a flat cable to the
main board. Before removing the cover locate the flat cable and disconnect.
Do this by opening the cover first for app 2cm (3/4 inch) and look inside. The
cover can be completely removed while the flat cable is attached, be careful
though. It is easiest to re-install when the flat cable is loosened at the side of the
cover. On both sides of the connector cover there is a small protuberance that
you can pry up using a screwdriver. Gently pull the flat cable(s) out of the
connector.
4. Remove the cover.
To re-install, proceed in the reverse order of removal. Make sure to firmly tighten all screws.
Note:
Make sure that you do not jam any wires between the cover and the side plate
as this may cause considerable damage.
Give special attention to the flat cables. Protruding parts inside the cover can
partly unconnect the flat cables and inflict serious damage to several PCB’s.
