S Class 2 cutter Service manual
Replacements guidelines 2-26
2.16 Replacing the pinch roller sensor
The pinch roller sensor is located on the rear side of the carriage. To replace the sensor,
follow the procedure to change the head, then replace the sensor. The sensor is fixed with
two screws at the bottom of the carriage.
Put a new sticker over the wires and then mount the head in its place.
