S Class 2 cutter Service manual
Replacements guidelines 2-25
Caution:
While checking height of the head, be sure not to push the knife holder
upwards.
6. Move the head all the way to the right to check if the OPOS sensor is pushed upwards.
The plastic part at the right side of the base plate should push the sensor 0.3mm to
0.5mm (movement visible in direction shown by 2 in changing head 7). If the OPOS sensor
is not stirred, then the head has to be re-positioned.
7. All previous pictures do not show the floorplate that is mounted on the bottom of the
head. The distance between this floorplate and de base should be 3.2mm. This is the
same as the thickness of normal vinyl plus the thick side of the height fixture. Mount the
cut of knife assy. Make sure there is no space between the assy and the floorplate.
Afterwards check if there is no gap and check if the distance is correct. If not re-install the
cut of knife assy. It is recommended to use tool version 2 (part number 395-111) to set
floorplate height.
8. Firmly tighten all the screws once the head is properly positioned.
9. Put the flat cable(s) back into the connector and close the connector. To ensure good
contact, the flat cable must be positioned as deeply as possible and in the middle of the
connector. Put the sensor connector back.
10. Remount the front cover of the head and firmly tighten the screws.
Note:
Now that you have replaced the head, it is extremely important that you bring
the data stored on the PCB in line with the head and vice versa. A spare head is
normally delivered with the correct settings. The section about calibration
explains how to calibrate.
