S Class 2 cutter Service manual
Replacements guidelines 2-5
2.5 Removing the bottom plate
To remove the bottom plate, proceed as follows:
1. Turn the unit upside down.
2. Remove the screws holding the bottom plate in place (the number of screws varies
depending on the cutter type).
3. Carefully remove the bottom plate, mind the fan cable.
To re-install, proceed in the reverse order of removal. Make sure to firmly tighten all screws.
Note:
Make sure the bottom plate is placed correctly into the slots of the bottom
plate.
2.6 Replacing the pinch rollers
To replace the pinch rollers, proceed as follows:
1. Remove the retaining ring at one side.
2. Remove the pinch roller shaft (push against the other side of the shaft).
3. Remove the pinch roller.
Note:
a. Pinch rollers come in pairs. When one is malfunctioning or broken, both need
to be replaced.
b. The models 120 have three, the 140 and the 160 four pinch rollers. The centre
pinch rollers are not matched with the two pinch cam rollers and can be
installed independently.
To re-install, proceed in the reverse order of removal.
