S Class 2 cutter Service manual
Replacements guidelines 2-11
2.10 Replacing the Y-motor
To replace the Y-motor, proceed as follows:
1. Remove the right-hand cover (see Section 2.4, removing the right-hand cover).
2. Loosen the screws of the power entry and pull it out leaving it hanging.
3. Remove the motor without encoder if machine type is 120, 140 or 160 (see 2.9.2)
4. Locate the motor and follow the cables from the motor to the main board. Disconnect
them.
5. Remove the nuts holding the motor in place (see picture for the exact position of the
nuts).
6. Carefully remove the motor leaving the belt hanging.
To re-install, proceed in the reverse order of removal. Make sure to firmly tighten all screws.
Note:
When re-installing, be extremely careful to plug the connector into the correct
positions.
