4.2.3.6 Confidence test
The Confidence test performs a quick electrical and mechanical test of the cutter to make
sure that the cutter is fully operational. A media sheet of at least A3/B- size should be used
for this plot. This test is always cut at the left side of the loaded media.
4.2.3.7 DIN A4 Test
The DIN A4 Test also performs an electrical and mechanical test of the cutter, in order to
check the cut quality, but also provides the user with feedback on knife setting, knife
pressure, knife offset and cutting depth.
This cut is always run as a DIN A4 portrait/A-size image, regardless of the actual size of the
media loaded. If the media loaded is smaller than DIN A4/A-size, part of the outer box will be
clipped (not cut).
4.2.4 ROM REVISION
Press the button to view information about the cutter’s ROM revision. This information is
often helpful to technicians when diagnosing problems over the telephone.
4.2.5 Configuration (Quick parameter change)
The S class cutters include 8 user configurations, all of which consist of the same parameters.
Each configuration can have unique parameter settings. This allows the cutter to be quickly
and easily reconfigured for different types of jobs or media.
NOTE: Factory default values for the different users are set all the same.
NOTE: The touch screen can be used to change user configurations. User configuration
names can only be modified through Summa Cutter Control (PC only).
Tip: Use easy names to recognize quickly for what the user was configured.
Common used names are: Normal; Pen; Slow; Sandblast; Pouncer; Red intermediate
vinyl…..
4.2.6 Pause (Online/Offline)
Online and offline are two important concepts when using the S Class cutters. The cutter is
online only when the status of the touch screen is similar to the below figure.
When online, the cutter can be addressed by the host computer, which means that the cutter
will execute cutting or plotting instructions issued by the host computer's application
software. As soon as a button is pressed the cutters comes offline.
