Summa S2 CLASS - Cut off Margin; Roll up Media; Autoload; Language

S Class 2 cutter Service manual
Basic Operation 4-7
4.2.2.6.3 Cut off margin:
The recut offset submenu is used to set or modify the distance the media moves forwards
after the last job before it is cut off.
Default value is 10mm.
4.2.2.6.4 Roll up media:
The roll up media submenu is used to set or modify the parameters of the roll up system.
Default value is off.
4.2.2.6.5 Autoload:
The Autoload option enables the user to change how the vinyl unrolls. When Autoload is on,
the cutter will automatically unroll the vinyl when needed. When the Autoload option is set
off, the operator himself should unroll enough media before starting to cut.
The default setting is on.
Note: Tracking is not guaranteed when Autoload is set to off.
4.2.2.6.6 Language:
This submenu is used to set or modify the dialogue language on the touch screen. When the
machine is new, it asks the user to choose a language. If this setting was set wrong by
mistake, then the language can be changed with this option.
The information on the touch screen can be displayed in English, French, German, Spanish,
Italian, Dutch or Polish.
The default language is chosen when the cutter is switched on for the first time.
4.2.2.6.7 Menu Units:
The setting of these options determines whether the speed and size values are displayed in
the metric measure system or ENG/US measure system.
The panel units are chosen when the cutter is switched on for the first time.
4.2.2.6.8 LCD contrast
The LCD contrast submenu is used to adjust the contrast (or intensity) of the touch screen.
The firmware automatically rejects values that would make the touch screen too dark to be
able to use it.
4.2.2.7 OPOS
4.2.2.7.1 Calibrate OPOS:
This test calculates automatically the distance between the center of the knife and the OPOS
sensor. This test should be done on black vinyl with white backing (to have the most contrast
between vinyl and backing).
4.2.2.7.2 Calibrate media (OPOS):
This test is used when the OPOS sensor has difficulties reading the sensors.
It checks if it can clearly see the difference between marker color and media. If necessary it
changes an internal parameter also.
