S Class 2 cutter Service manual
Basic Operation 4-3
4.2.1 Service
This bundles the entire menu only visible in service mode.
4.2.1.1 Calibrate margin
The calibrate margin submenu is used to set the mechanical origin so that the cutter does
not cut inside the track the pinch rollers make in normal use.
4.2.1.2 Select machine
The selection machine type submenu is used to set the machine type correct. This is very
important. If machine type is set incorrect, then it will be impossible to load media. This
submenu also takes care of the motor parameters en maximum velocities.
4.2.1.3 System registers
The system registry submenu is used to show the value of all registries. It is not advised to
make changes in the registry values. This submenu can be used to troubleshoot problems
together with a Summa technician over the phone. It is possible that some values will be
asked.
NOTE: Do not change values without first checking with a summa employee.
4.2.1.4 Install roll up system?
On roll-up option installation, this menu item needs to be used to enable the roll-up.
4.2.1.5 Check media weight
This menu option can be used to determine which X-axis motor may need to be replaced.
4.2.1.6 Monitor
The monitor submenu is a very handy tool that shows the output levels all all sensors and
encoder on one screen.
4.2.1.7 Burn in
The burn in submenu is used in the factory to start a test that takes 16 hours, but tests all
mechanical parts.
NOTE: Do not use this test in the field without first checking with a summa employee.
