S Class 2 cutter Service manual
Replacements guidelines 2-14
2.12 Replacing the pinch roller switch
To replace the pinch roller switch, proceed as follows:
1. Remove the right-hand cover (see Section 2.4, Removing the right-hand cover).
2. Remove tie wraps of the cable from the switch to the main board.
3. Disconnect the connector from the main board.
4. Loosen the 2 screws of then switch.
To re-install, proceed in the reverse order of removal. Make sure to firmly tighten all screws.
Note:
When re-installing, make sure that the cable cannot touch any moving parts
