S Class 2 cutter Service manual
Basic Operation 4-9
4.2.2.8 Communication
4.2.2.8.1 Tool Commands
TOOL COMMAND is used to determine whether the DM/PL and HP-GL tool commands (pen
select pressure and velocity) are ignored or accepted.
4.2.2.8.2 USB Class
USB class can be set to Summa USB port 1, Summa USB port 2, Summa USB port 3, Summa
USB port 4 or Printer Uni.
Printer Uni is for using the windows printer spooler.
Because of the different USB id’s, the computer can make a distinction between several
cutters attached to it (maximum 4).
4.2.2.8.3 LAN
A couple of parameters have to be set when connecting a cutter to the Ethernet. It is best to
check a couple of network settings or ask the network administrator for following info:
Is the network working with DHCP server or not?
If so, what is the lease time and what is the IP pool range of the DHCP server.
If not, then find out what the used IP range is.
Also ask for the value for the subnet mask.
4.2.2.9 Calibrate X(/Y)
Calibrate X(/Y) allows the length of the lines cut to be adjusted to within the specifications.
For instance, if a cut line should measure 100 mm exactly, the cutter can be adjusted for any
discrepancy.
NOTE: The cutter will only be as accurate as the accuracy that is used while calibrating. If
the ruler is inaccurate, then it is possible that re-calibrating makes the cutter’s accuracy
worse. The accuracy used while calibrating is going to be directly reflected to the cuts. It is
recommended to set the cutter to Metric to do the calibration. It is more accurate than the
English system.
Check the calibration section for the exact calibration description
4.2.2.10 Coil Setup
This test is used to calibrate knife and pen pressure and to set the knife and pen “landing”.
The cut quality is seriously affected by wrong landing settings. Before changing these values,
write them down, there is no default setting for these parameters.
After adjustment, the value is saved in the system’s non-volatile RAM.
4.2.2.11 Factory defaults
This option defaults all user parameters to factory default. The parameters that require
calibrating are not reset.
