S Class 2 cutter Service manual
Calibration 3-2
3.1 Machine type
The machine type can be set by either Summa Cutter Control or via the touch panel. It is not
advised to change the machine type via touch panel. This means entering service mode.
Caution:
Service mode is reserved for technician trained by Summa.
3.1.1 The machine type has to be reset when:
The PCB has been changed
3.1.2 Configuration of the PCB:
3.1.2.1 Via keyboard:
1. Initiate a start-up in Service Mode. Do this by switching on the unit while pressing tin the
upper left corner of the display until a warning message appears on the touch screen.
Caution:
When starting in service mode, no load procedure is carried out. To make the
unit operational, a load procedure has to be carried out (see User’s Manual). If
this load procedure is not carried out, the unit may crash.
2. Service mode activates an extra menu in the configuration menu.
3. To change machine type, go into this menu, select sub “menu machine” type and set
machine type correct.
Caution:
If the machine type is not set correct then the unit may crash.
In service mode the following extra items appear under service menu:
a. Calibrate margin
b. Selection Machine type
c. System registers
d. Burn in
e. OPOS monitor
f. hardware test
g. flash used
h. monitor
