S Class 2 cutter Service manual
Basic Operation 4-10
4.2.2.12 Copy current user
Press the button to copy the user parameters from the current user to all the other users. It is
recommended to do this only when the current user is user 1.
4.2.2.13 Media Sensor Setup
The Media Sensor Setup option is a useful routine to check whether or not the front and rear
media sensors are functioning properly and whether the switching levels of these sensors are
correctly set.
4.2.2.14 Calibrate Touch Screen
This option makes it possible to calibrate the touch screen. Perform this calibration if the
illustration of the button on the touch screen does not match the area that needs to be
pressed to activate the button.
Press button to start the calibration and follow guidelines on screen.
4.2.3 Actions
4.2.3.1 Load
The Load instruction is used to initiate a load sequence. There are three different load
methods (roll, sheet, extended). OPOS barcode initiates the barcode reading routine. Roll up
roll the rest of the media up.
4.2.3.2 Reset
This is used to interrupt an ongoing job. It clears the internal buffer and communication ports.
4.2.3.3 Replot
Each job is stored in the cutter’s memory until a new job is sent. Pressing replot allows the job
to be replotted. After this button is pressed, the user may choose the number of replots. The
replot button does not work if there is no job in the memory, or if the previous job was larger
than the cutter’s memory.
4.2.3.4 Cut Sheets
Use this function to cut off a defined number of sheets from a roll with a fixed length.
4.2.3.5 Open file
Use this to cut directly from the USB flash drive or to upgrade the firmware of the cutter.
