4. USB port type A female: For plugging in a USB stick.
5. Ethernet port RJ45: For connecting the cutter to the LAN.
6. USB port Type B female: This interface is based on the standards specified in Universal
Serial Bus Specifications Revision 1.1. It allows a high-speed bi-directional communication
between the host computer and the cutter.
7. Pinch roller lever: This lever is used to raise and lower the pinch rollers for media loading.
8. Roll media guide bushes: The two flange guides serve to keep the media roll in place
when media is pulled from the roll.
9. Pinch rollers: The pinch rollers clamp the media to the drive system to ensure accurate
tracking. The S120(T) has one and the SS160(T) and S 140(T) have two extra pinch rollers
to ensure that wide media stays flat in the middle. The outer drive pinch rollers have a
selectable pressure; the extra rollers in the middle can be enabled or disabled. Do not
move the pinch roller assemblies while holding them from this side only.
10. Screws to secure the cutter base: Screws (3 left and 3 right) hold the cutter base to its
stand. All the screws must be properly tightened before using the cutter.
11. Tubes for media basket: Tubes in the back and front hold the media basket. They can
easily pulled outwards to put the basket in its place.
12. Casters: The casters on the stand are equipped with locking brakes. Once the cutter has
been moved to its new location, press the brakes with your foot to lock the casters.
13. Media support rollers: Rotating support rollers for the media roll.
14. Media basket: The stand and linen media basket come as standard equipment with all S
CLASS 2 cutters.
