Appendix D Connecting to the 2510 Array with Other Topologies 123
You can connect one or more hosts to a controller tray. The hosts can run the same
operating system or each host can run a different type of operating system.
FIGURE D-3 Fabric Topology – Two Hosts Connected to the Controller Through a Switch
1. Hosts
2. NIC 1
3. NIC 2
4. Host Port 1
5. Host Port 2
6. Controller A
FIGURE D-4 Mixed Topology – Three Hosts Connected Through a Switch or Connected
Directly
1. Host 1
2. NIC 1
3. NIC 2
4. Host 2
5. Host 3
6. Host Port 1
