56 Sun StorageTek 2500 Series Array Hardware Installation Guide • September 2009
Note – Before you begin, ensure that the two required Ethernet cables are available.
These requirements are outlined in the StorageTek 2500 Series Array Site Preparation
Guide.
There are three ways to establish a connection between the management host and
Ethernet port 1 of a controller module:
■ “Attaching the Ethernet Ports to the LAN of the Management Host” on page 56
■ “Attaching the Ethernet Ports to the Management Host Using an Ethernet Hub”
on page 56
■ “Attaching the Ethernet Ports Directly to the Management Host With a Cross-
Over Cable” on page 57
Attaching the Ethernet Ports to the LAN of the
Management Host
To attach the Ethernet ports to the local area network (LAN) of the management host:
1. Locate the Ethernet port for Controller A and Controller B at the back of the
controller tray (
FIGURE 3-1).
2. Connect Ethernet cables to the Ethernet ports of each controller.
3. Connect the other end of each Ethernet cable to the LAN on which your
management host resides (preferably on the same subnet).
Attaching the Ethernet Ports to the Management
Host Using an Ethernet Hub
To attach the Ethernet ports and the management port Ethernet interface to an
Ethernet hub on a private subnet:
1. Locate Ethernet ports on Controller A and Controller B at the back of the
controller tray (
FIGURE 3-1).
2. Connect Ethernet cables to the Ethernet ports of each controller module.
3. Connect the other end of each Ethernet cable to an Ethernet hub.
4. Connect an Ethernet port on the management host to the Ethernet hub.
