Chapter 2 Installing Trays 29
FIGURE 2-1
Note – The rails are pre-configured to adjust to cabinet rail depths of between 24
inches (609.6mm) and 34 inches (863.6mm).
Preparing the Tray
Caution – Two people are needed to lift and move the tray. Use care to avoid injury.
A tray can weigh up to 54.3 pounds (24.6 kg).
1. Unpack the tray.
2. Check the contents of the box for the following items:
■ Sun StorageTek 2500 Series Array trays (controller or drive expansion)
■ Ship kit for the controller tray
■ One pair left and right end caps (plastic bezels)
■ Four 4Gbps FC SFPs (2 per FC controller module - ST2540 Array only)
■ One 6-meter RJ45 -RJ45 Ethernet cables
■ One RJ45-DIN9 cable
■ One RJ45-DB9 adapter
■ One RJ45-DB9 null modem adapter
■ Sun StorageTek Common Array Manager Software CD
■ Sun StorageTek Common Array Manager Software Installation Guide (on the
software CD)
■ Common Array Manager sscs CLI Quick Reference Card
■ Sun StorageTek 2500 Series Array Hardware Installation Guide (Hardcopy)
■ Accessing Documentation guide
■ Premium feature license cards (ordered optionally)
■ Ship kit for each expansion tray
■ Two 1-meter copper SAS cables (one per I/O module)
■ Accessing Documentation guide
AC power cords are shipped separately with each tray.
