Chapter 3 Connecting the Management Host 57
Attaching the Ethernet Ports Directly to the
Management Host With a Cross-Over Cable
Note – This method would typically be used only to establish temporary IP
connectivity between the management host and the controller’s Ethernet ports.
To attach the Ethernet ports directly to the management host using cross-over cables:
1. Locate the Ethernet ports for Controller A and Controller B at the back of the
controller tray (
FIGURE 3-1).
2. Obtain and connect Ethernet cross-over cables to the Ethernet port of each
controller module.
3. Connect the other end of each Ethernet cable directly to your management host
Ethernet ports.
Next Steps
Now You Are Ready To Connect The Data Host To Your Array, As Described In
Chapters 4 to 6.
