18 Sun StorageTek 2500 Series Array Hardware Installation Guide • September 2009
4 Cache Active Green Steady green indicates that data
is in the cache.
Indicates that all data has been
written to the disk and the cache
is empty.
5 Service Action
Allowed
Blue The controller can be removed
from the controller tray.
The controller cannot be
removed from the controller tray.
6 Service Action
Required (Fault)
Amber Indicates a fault within the
controller.
Normal condition
7 Power Green Tray is powered on. Tray is not powered on.
8 Ethernet Link Green The connection is active. The connection is not active.
9 Ethernet
100BASE-TX
Green 100BASE-TX connection is
active.
The 100BASE-TX connection is
not active.
TABLE 1-4 Descriptions of the Controller LEDs on the Sun StorageTek 2530 Array (2 of
