SWDE200B Operation & Maintenance Manual
39
Left Lever
(Saline)
Note: only when clamping claw
opens
3-Fan switch;
4-Drill-rod lifting switch;
5-Horn switch;
6-Grease filling switch;
7- Claw open
Left Lever
(Xiaolong)
LED 1-Indicator Light, standby；
LED 2-Indicator Light, standby;
1-Grease filling switch;
2-Fan switch;
3-Horn switch;
4- Drill-rod lifting switch;
7- Claw open
turntable rotate clockwise
turntable rotate anticlockwise
mechanical arm in
mechanical arm out
