15. Steering / Front Wheel / Front Cushion
15-10
Lubricate the top cone race seat with grease.
Screw the cone race in to top ball bearing seat till
touching, and then screw out the cane race
1/4~3/8 turns.
Torque value: 0.25kgf-m
Caution
y Check the steering stem that should be
rotated freely and no clearance in vertical
direction.
Install the steering stem mounting nut and tighten
the nut by means of holding the top cone race
body.
Torque value: 1.0~2.0kgf-m
Install in reverse order of removal procedures.
Steering lock nut
Top cone-race
Return 1/2 turns
Locking to
1/4~3/8 turns
