Chapter 4: Removal and Reinstallation Procedures
4 –33
Adjusting
STEP 1. Install paper, turn printer on a d enable Tech Access. In the Meter Parameter of the control
panel, select Shuttle Sensor.
STEP 2. Turn the shuttle by hand until the solid side of shuttle gear is directly over the sensor. Move
the sensor by hand until the control panel reading is less than 0.5V, then tighten screw.
If the sensor cannot be adjusted when the solid portion of the shuttle gear is over it so
that the low reading is less than 0.5 volts, remove and replace the sensor.
STEP 3. Turn shuttle by hand until open side of shuttle gear is directly over the sensor. Check the
voltage reading on the display. The reading should be greater than 4.5V.
If the sensor does not read greater than 4.5V when the open portion of the shuttle gear is
over it and the low reading is less than 0.5 volts, remove and replace the sensor.
Both readings have to match specifications at the same sensor adjustment in
order to obtain optimum print quality.
