Chapter 1: Electronic Hardware Architecture, Performance & Specifications
1–7
Table 1–4. Graphics Benchmarks
AIAG Label Benchmark Results
Graphics Dots Per In.
Language 60 120
Code V 1950 LPH 1300 LPH
PGL 1950 LPH 1300 LPH
Table 1–5. POSTNET Label Speeds
POSTNET Label Benchmark Results
Lines Type Style
Per Inch Draft Data Processing
6 LPI 32000 LPH 29000 LPH
8 LPI 33000 LPH 30500 LPH
Paper Slew Speed
Table 1–6. Slew Speed
Print Mode Maximum Slew Speed
Normal 16 Inches Per Second
Heavy Forms 12 Inches Per Second
Ribbons
The T6090 is designed to operate optimally with Tally ribbon cartridges. These cartridges are
designed for easy access and loading.
Forms/Paper Description
The T6090 is designed to use continuous, sprocket feed type paper, 3 to 16.53 inches in width,
and 3 to 12 inches in length. One to six part paper may be used with a maximum thickness of
.025 inches. (Reference specifications: ISO 2784, DIN 9771, and DIN 6721.)
