Chapter 3: Troubleshooting
3–19
Table 3–5. T6090 Hammer Coil/Module Troubleshooting
Print Hammer Hammer CBA Print Hammer Hammer CBA
Columns Coil Module Driver Columns Coil Module Driver
1 & 2 1 1 U20 67 & 68 34 12 U12
3 & 4 2 1 U20 69 & 70 35 12 U11
5 & 6 3 1 U20 71 & 72 36 12 U11
7 & 8 4 2 U19 73 & 74 37 13 U11
9 & 10 5 2 U19 75 & 76 38 13 U11
11 & 12 6 2 U19 77 & 78 39 13 U10
13 & 14 7 3 U19 79 & 80 40 14 U10
15 & 16 8 3 U18 81 & 82 41 14 U10
17 & 18 9 3 U18 83 & 84 42 14 U10
19 & 20 10 4 U18 85 & 86 43 15 U9
21 & 22 11 4 U18 87 & 88 44 15 U9
23 & 24 12 4 U17 89 & 90 45 15 U9
25 & 26 13 5 U17 91 & 92 46 16 U9
27 & 82 14 5 U17 93 & 94 47` 16 U8
29 & 30 15 5 U17 95 & 96 48 16 U8
31 &3 2 16 6 U16 97 & 98 49 17 U8
33 & 34 17 6 U16 99 & 100 50 17 U8
35 &36 18 6 U16 101 & 102 51 17 U7
37 & 38 19 7 U16 103 & 104 52 18 U7
39 & 40 20 7 U15 105 & 106 53 18 U7
41 &4 2 21 7 U15 107 & 108 54 18 U7
43 & 44 22 8 U15 109 & 110 55 19 U6
45 & 46 23 8 U15 111 & 112 56 19 U6
47 & 48 24 8 U14 113 & 114 57 19 U6
49 & 50 25 9 U14 115 & 116 58 20 U6
51 & 52 26 9 U14 117 & 118 59 20 U5
53 & 54 27 9 U14 119 & 120 60 20 U5
55 & 56 28 10 U13 121 & 122 61 21 U5
57 & 58 29 10 U13 123 & 124 62 21 U5
59 & 60 30 10 U13 125 & 126 63 21 U4
61 & 62 31 11 U13 127 & 128 64 22 U4
63 & 64 32 11 U12 129 & 130 65 22 U4
65 & 66 33 11 U12 131 & 132 66 22 U4
Driver Information is intended for Service Center only.
