Table 3–4. P703 & P704 Connector to Hammer Bank CBA Continuity Check Points
1234 5 6 78 91011
3 6 9 1215182124273033
Hammerbank Firing Line — Top View — Left to Right
Power
Supply Pins
Hammers
{
Hammer
Modules
{
Hammerbank CBA Soldered Connections
J6
J5
P703 Pin Numbers
Connector Alignment
P704 Pin Numbers
P703 Hammerbank Ribbon Cable P704 Hammerbank Ribbon Cable
43 1357911131517192123252729313335373941
44 24681012141618202224262830323436384042
43 1357911131517192123252729313335373941
44 24681012141618202224262830323436384042
2 5 8 1114172023262932
1 4 7 1013161922252831
48V 48V 48V 48V 48V 48V 48V 48V 48V 48V 48V
35 38 41 44 47 50 53 56 60 63 66
36 39 43 45 48 51 54 57 59 62 65
34 37 40 43 46 49 52 55 58 61 64
48V 48V 48V 48V 48V 48V 48V 48V 48V 48V 48V
