Table 1–2. Type Style, Character Matrix, Dot Density, and CPI Combinations
Print Modes Type Styles 10 CPI Group 12 CPI Group 15 CPI Group
Constant Density Draft Base Matrix: 9 x 8 Base Matrix: 7 x 8 Base Matrix: 5 x 8
Dot Density: 60 x 48 Dot Density: 60 x 48 Dot Density: 60 x 48
CPIs: 5 and 10 CPIs: 6, 6.67, 12, CPIs: 15 & 17.14
& 13.33
Data Processing Base Matrix: 9 x 12 Base Matrix: 7 x 12 Base Matrix: 5 x 12
Dot Density: 60 x 72 Dot Density: 60 x 72 Dot Density: 60 x 72
CPIs: 5 & 10 CPIs: 12 & 13.33 CPIs: 15 & 17.14
Enhanced Draft Base Matrix: 9 x 8 Base Matrix: 13 x 8 Base Matrix: 9 x 8
Dot Density: 60 x 48 Dot Density: 80 x 48 Dot Density: 120 x 48
CPIs: 5 &10 CPIs: 6, 6.67, 12, CPIs: 7.5, 8.33, 8.57,
& 13.33 15, 16.67, 17.14, & 20
Data Processing Base Matrix: 9 x 12 Base Matrix: 13 x 12 Base Matrix: 9 x 12
Dot Density: 60 x 72 Dot Density: 80 x 72 Dot Density: 120 x 72
CPIs: 5 & 10 CPIs: 6, 6.67, 12 CPIs: 7.5, 8.33, 8.57, 15,
and 13.33 16.67, 17.14, & 20
Near Letter Quality Gothic Base Matrix: 19 x 16 Base Matrix: 13 x 16 Base Matrix: 9 x 16
Dot Density: 80 x 96 Dot Density: 80 x 96 Dot Density: 120 x 96
CPIs: 5 &10 CPIs: 6, 6.67, 12, CPIs: 7.5, 8.33, 8.57,
& 13.33 15, 16.67, 17.14, & 20
Courier Base Matrix: 19 x 16 Base Matrix: 13 x 16 Base Matrix: 9 x 16
Dot Density: 80 x 96 Dot Density: 80 x 96 Dot Density: 120 x 96
CPIs: 5 & 10 CPIs: 6, 6.67, 12, CPIs: 7.5, 8.33, 8.57,
& 13.33 15, 16.67, 17.14, & 20
Optical Character OCR-A Base Matrix: 9 x 16
Recognition Dot Density: 60 x 96
CPIs: 10
OCR-B Base Matrix: 19 x 24
Dot Density: 80 x 144
CPIs: 10
Lines Per Inch
Nine lines per inch (LPI) settings are available through the control panel. They include 1.5, 2,
3, 4, 5, 6, 8, 9, and 10 LPI. In some emulations the availability of certain LPI’s are restricted.
