T6090 Maintenance Manual
1–10
Heat Load Contribution
The average heat load contribution to the environment is approximately 580 BTUs per hour
(170 Watts) with a maximum potential of 1677 BTUs per hour (491 Watts) under continuous
full-load printing conditions.
Table 1–9. Heat Load Contributions
Printing Conditions (110 VAC/60 Hz) Current/Wattage BTU/Hr
Power On, not printing 0.64 A/42 W (>5 min.) 143
100% Uppercase Rolling ASCII 2.57 A/268 W 915
Black Page Plot 6.29 A/491 W 1677
Physical Configurations
The T6090 printer is available in the following configurations:
Standard Tabletop Printer
Optional Printer with Stand
Optional Printer with Quietized Pedestal
Before installing a Tabletop model, make sure that an opening has been provided in the
table that allows access to the paper path opening on the bottom of the printer.
Weight
Table 1–10. Actual Weight: Main Components
Component Weight
Tabletop Printer 90 lbs
Stand 30 lbs
Pedestal 52 lbs
Table 1–11. Actual Weight: By Configuration
Option Weight
Tabletop Printer 90 lbs
Printer plus Stand 120 lbs
Printer plus Pedestal 142 lbs
Table 1–12. Shipping Weight: By Configuration
Option Weight
Tabletop Printer 110 lbs
Printer with Stand 150 lbs
Printer plus Pedestal 185 lbs
