B-7
Appendix B: Recommended Spare Parts, Illustrated Parts Breakdowns, and Component Lists
Reference # Description Part Number
17 Platen Assembly 080953
21 Platen Lever Detent Plate 080931
23 3/8" Spring Washer 400995 – 20
24 Platen Open Sensor
Cable Assembly 080185
25 Platen Position Label 081008
27 Platen Gap Adjust Plate 080618
28 242 Thread Locking Adhesive 730213
29 8–32 x 0.625 Set Screw (2 ea) 400236 – 107
30 Platen Adjust Spring 731114
44 Extension Spring 731694
45 Shuttle Drive Motor 078259
48 LH Pivot Bracket Assembly 081231
51 RH Pivot Bracket Assembly 081232
54 8–32 x 0.38 SEMS Screws (4 ea) 402524 – 41
55 6–32 x 0.25 SEMS Screws (3 ea) 402524 – 21
56 8–32 x 0.50 SEMS Scrrews (10 ea) 402524 – 43
57 4–40 x 0,50 SEMS Screw (1 ea) 402524 – 03
59 8–32 x 1.25 Socket Head
Screw (2 ea) 400512 – 254
60 8–32 x 1.0 Socket Head
Screw (2 ea) 400512 – 252
61 Lower Paper Guide Assembly 080626
62 Stabilizer Block Assembly 078549
63 Stabilizer Support Bracket 080656
64 Shuttle Sensor Cable Assembly 081123
65 Upper Paper Guide 081230
67 Flat Belt Pulley Assembly 075490
68 Nylon Linear Bearing 402898 – 01
69 Paper Guide Wire Form 080632
76 Bronze Flanged Bushing,
Oil Impregnated 400844 – 04
80 8–32 x 0.437 SEMS Screw (4 ea) 402524 – 49
81 #8 Split Lock Washer (4) 400215 – 10
82 #8 Flat Washer 400216 – 10
