Appendix B: Recommended Spare Parts, Illustrated Parts Breakdowns, and Component Lists
Reference # Description Part Number
9 Frame End-plate Assembly 080698
31 Adhesive Activator 732239
32 Double-sealed Bearing with Ring 731090
33 Paper Drive Shaft 081186
34 Tractor Support Shaft 080649
35 Upper Paper Drive Tractor/Sensor Set 080877
36 1/8" Flush Hole Plug 732182
37 8–32 x 5/8" SEMS Screw (3ea) 402524 – 51
38 Retaining Ring 400641 – 18
39 Square Shaft Bushing 075480
40 5/16" x 18 thread KEPS Hex Nut 400783 – 15
42 Paper Spring 602631 – 1
43 Idler 075477
45 Paper Movement Motor 078259
46 Paper Motor Extension Cable 079677
47 Paper Drive Timing Belt 075127
49 Upper Tractor Drive Pulley 080635
50 Paper Motor Drive Pulley 080711
52 Paper Motor flywheel 080733
53 8–32 x 0.50 Set Screw (2 ea) 400690 – 67
54 8–32 x 0.38 SEMS Screw (1 ea) 402524 – 42
56 8–32 x 0.50 SEMS Screw (7 ea) 402524 – 43
58 Lower Tractor Drive Pulley 080647
70 Phasing Lever Guard 081339
71 Phasing Bracket Assembly 080636
72 Spring Plunger 403738 – 1
73 Left Linear Bearing Mount Assembly 080653
74 Bearing Mount Support 081344
75 5/16" Curved Spring Washer (2 ea) 730186
78 Lower Idler Assembly 080944
79 8–32 x 0.875 SEMS Screw (1 ea) 402524 – 48
80 Lower Paper Drive Tractor/Sensor Set 081128
