B-11
Appendix B: Recommended Spare Parts, Illustrated Parts Breakdowns, and Component Lists
Reference # Description Part Number
1 Shuttle Assembly 081149
2 Ribbon Shield 081298
3 Bearing Block, Right 081236
4 Fan 079644
5 Power Supply 081153
11 Bearing Block, Left 081237
14 Hammert Bank Duct 080727
15 Hammer Bank 081144
16 Print Mechanism 080699
22 832 x 0.437 SEMS Screw (4 ea) 402524 – 49
34 8–32X 2.00 SEMS Screw (1 ea) 731723
37 4–40 x 0.25 82° 400258 – 01
39 8–32 x 0.875 SEMS Screw 4 ea 402524 – 48
40 Personality CBA (Ser/Par) 080901
Personality CBA (4 Plex) 081086
Personality CBA (Lan) 080920
46 Nylon Twist-lock Cable Support (3ea) 730755
50 2.5" Electrical Tape 730597
51 Hardware Removal Flag 79400
52 Engine Controller CBA 080873
54 4–40 x 1/4" SEMS Screw (6 ea) 402524 – 01
60 Duct Cable Clamp Bracket 080768
61 Cable Protector Pad 081097
62 6–32 x 0.50 SEMS Screw 402524 – 23
63 I/O Personality Module Housing 080868
64 4–40 x 0.375 82° Flat Head Screw 400258 – 02
65 I/O Module Insertion Guides (2 ea) 732165
